1BJY-EW-01 Trailer Parts and Accessories Capacity 12000lbs Trailer Electric Winch Kit for ATV/UTV

#detail_decorate_root .magic-0{width:750px}#detail_decorate_root .magic-1{overflow:hidden;width:750px;height:532.8719723183391px;margin-top:0;margin-bottom:0;margin-left:0;margin-right:0}#detail_decorate_root .magic-2{margin-top:0;margin-left:0;width:750px;height:532.8719723183391px}#detail_decorate......Keywords:1bjy-ew-01 Trailer Parts And Accessories Capacity 12000lbs Trailer Electric Winch Kit For Atv/utv - Buy 1bjy-ew-01 Trailer Accessories Trailer Electric Winch Product on CMN Industry Inc

Send Inquiry

Product Description

Powerful power - rated tension of 2000 pounds, powered by a 1 horsepower (12 volts) DC motor Efficient - Line speed of 3.3 feet per minute when fully loaded and 10.5 feet per minute when unloaded Convenient - including installation channels, remote controls, and roller cable guides, creating an unprecedented and effortless winch experience Worry free - The drum cable guide adopts reliable 49 foot galvanized ultra heavy aircraft cable, which can withstand abrasive terrain without wear and tear, thus achieving safe and smooth pulling.

JY NO.	Gear ratio	MountingBolt pattern	Capacity	Motor
1BJY-EW-01	265:1	254mmx114.3mm	12000LBS	3.9kw/5.35hp, series wound
1BJY-EW-02	235:1	254mmx114.3mm	8500LBS	3.2kw/4.3hp, permanent magnet
1BJY-EW-03	312.4:1	254mmx114.3mm	16000LBS	12V 5.6hp/4.2kw 24V 6.17hp/4.6kw,series wound
1BJY-EW-04	265:1	255mmx114mm 11	9500LBS	3.6kw/4.9hp, permanent magnet
1BJY-EW-05	235:1	255mmx114mm ¢11	8000LBS	3.0kw/4.1hp, permanent magnet
1BJY-EW-06	235:1	165mmx114mm 11	6000LBS	2.0kw/2.7hp, permanent magnet
1BJY-EW-07	265:1	255mm*114mm, 0111B	10000LBS	3.9kw/5.35hp, series wound
1BJY-EW-08	265:1	254mmx114.3mm	13000LBS	4.1kw/5.6hp, series wound
1BJY-EW-09	358:1	254mmx114.3mm	15000LBS	4.0kw/5.4hp, series wound
1BJY-EW-10	358:1	254mmx114.3mm	16800LBS	4.4kw/6.0hp, series wound
1BJY-EW-11	153 :1	285mm*105mm	2000LBS	12v/1.0hp permanent magnet
1BJY-EW-12	153:1	285mm*105mm	3000LBS	0.9kw/1.2hp/12vpermanent magnet

Applications of Trailer Electric Winch

Applications of Trailer Electric Winches
Electric winches are powerful tools that significantly enhance the convenience and efficiency of trailer operations. Here are some
of their primary applications:
Boat Trailers:
Loading and Unloading: Electric winches make it easier to load and unload boats onto trailers, especially larger vessels.

Boat Retrieval: In challenging water conditions, a winch can help retrieve a boat from the water.

RV Trailers:
Leveling: Electric winches can assist in leveling the RV on uneven terrain.
Deploying Slide-outs: Some RVs use winches to extend and retract slide-out sections.

Cargo Trailers:
Loading and Unloading: Winches can help load and unload heavy cargo, such as construction materials or agricultural equipment.
Securing Loads: Winches can be used to secure loads to the trailer bed.

Utility Trailers:
Loading and Unloading: Winches can assist in loading and unloading heavy equipment, such as lawnmowers, generators, or other
tools.
