Product Description

Characteristics:

apply scope WS-and WSD-Cross axle universal coupling is suit for rotating system which the two axis angle ẞ ≤45,

Nominal torque 11.2~1120N.m

A universal joint, (universal coupling, U-joint, Cardan joint, Hardy-Spicer joint, or Hooke's joint) is a joint or coupling in a rigid rod that allows the rod to 'bend' in any direction, and is commonly used in shafts that transmit rotary motion. It consists of a pair of hinges located close together, oriented at 90° to each other, connected by a cross shaft. The universal joint is not a constant velocity joint. No machine element other than a cardan shaft allows power transmission of torque between specially offset driving and driven shafts whose position can be changed during operation. Spatial angular motion and changes of axial length are ensured by advanced constructional elements. Thus, cardan shafts have become an indispensable transmission component in automotive engineering and industry.

Cardan shafts offer 1.multifunctional application 2.excellent efficiency 3.high reliability 4.low maintenance 5.easy use They are an integral part in almost all industries with mechanical drives. Convince yourself that our products will solve your drive problems to your complete satisfaction. Selection and use of cardan shafts Cardan shafts being used for various applications. So it is impossible to select their size and predict their lifetime with reliable accuracy with just one general rule. The familiar failure probabilities for roller bearings apply to cardan shafts as well. The size of the cardan shaft should be chosen so that its maximum momentary torque rating, is not smaller than the maximum torque to be transmitted in your application. Additionally parameters like deflection angle, speed, length, operating conditions (kind of drive, temperature, dust etc.) should be considered. Therefore please refer to our technical questionnaire. Our experts will evaluate your information given in this questionnaire, to find the best choice for your application. If you need more detailed calculations like determining lifetime, stability etc. please contact us.

For more details, please click here to contact us！

Our company is a large-scale expert company with mechanical transmission design, manufacting and marketing. Our compay has the first-class production equipment in China and advanced QC measurement, together with a highly qualified team. Over the years, to meet the reauirements of customers, we insist in" high quality, good faith" and attract high-tech talents,d igest assimilate advancecl foreign technology, constant innovation, producting a large number of high-tech, high-quality transmission machine. Our company is not only widely recognized by customers, but also a fresh power in national transmission industry. We have built complete quality and management guarantee, obtained the ISO9001 certificat. So far we own more than 8 series, total over 300types of shaft coupling, more than 20 series, total thousand types of coupling sleeve. We also can produce special size products cater to requirement of customers. These products are widely used in metallurgical, chemical, printing, pumps, fans, transport machinery, and other fiels, and exports to the Far East and Southeast Asia. We believe that superior quality is the basis of mutual benefit and trust to broaden win-win economic cooper. Welome the masses of old and new customers to patronize cordially!

Q: Are you trading company or manufacturer ? A: Our group consists in 3 factories and 2 abroad sales corporations. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: How long is your delivery time ? What is your terms of payment ? A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment. Q: What is the exact MOQ or price for your product ? A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.

FOR MORE DETAIL, PLEASE CONTACT US.
