Product Description

NM flexible shaft coupling is a cylindrical pin made of some non-metallic materials, which is placed between the two sides of the coupling and the inner surface of the outer ring, and a device to transfer the torque through the column pin to realize the connection between two half couplings. NM flexible shaft coupling between the slider made of bakelite cloth or polyurethane, suitable for high speed, large torque, no sharp impact of the two connections.

ParameterProduct brand: EVER-POWER

Name of transmission part: water pump coupling

Product structure: it is composed of two cast iron claws and a natural rubber inner ring

Suitable shaft diameter: 7mm-75mm

Suitable motor power: within 60hp / 45KW

Product features:

1. The maximum torque is 125kgm2. Stable operation and low noise3. The product is made of cast iron and cast by precision die casting, so it is not easy to cause fracture during operation

Click this products picture can look over the relevant products

Click here for more details！

Packaging:
Chain+Plastic Bag+ Carton+Wooden case( If you have other requirements, we can customized according to customer requirements packaging. )

Shipping :
1.Most of the standard ones are in stock which we can send in 3-10 days after inspection and package.
2. Customized products delivery time should be determined according to the number.
