Product Description

High precision, high performance, high efficiency

Five axis machining, modular design

Strong braking system

Product Model	RT-170	Servo motor (optional)	β8iFANUC ;β8iFANUC
Panel Size	170mm	Reduction Ratio	1:60 ;1:72
Disk Aperture	55mm	Maximum Rotation Speed Of Worktable	55.5 r.p.m
T-groove Of Disk Surface	14H8mm	Minimum Setting Angle	0.001°deg
Tilt Angle	±110°deg	Segmentation Accuracy	20″sec;15″sec
Rotation Angle	360°deg	Repeat Positioning Accuracy	4″sec;4''sec
0 ° Time Disk Height	240mm	Locking torque of rotating shaft	310N.m;500N.m
90° Time Center Height	230mm	Brake Pressure	5Kg/cm²;10Kg/cm²
Net Weight (about)	160Kg	Allowable Cutting Force	18Kgf-m;20Kgf-m
Horizontal placement	40KG	Ninety ° Time	20 KG
