Product Description

Products Description

High precision, high performance, high efficiency

Five axis machining, modular design

Optional fixture oil circuit, Optional hydraulic brake

Product Model	RTS-200	Servo motor (optional)	β2iFANUC ;β8iFANUC
Panel Size	200mm	Reduction Ratio	1:121 ;1:90
Disk Aperture	40mm	Maximum Rotation Speed Of Worktable	33.3 r.p.m
T-groove Of Disk Surface	12H8mm	Minimum Setting Angle	0.001°deg
Tilt Angle	±110°deg	Segmentation Accuracy	20″sec;15″sec
Rotation Angle	360°deg	Repeat Positioning Accuracy	4″sec;4''sec
0 ° Time Disk Height	255mm	Locking torque of rotating shaft	412N.m;450N.m
90° Time Center Height	135mm	Brake Pressure	;15Kg/cm²
Net Weight (about)	180Kg	Allowable Cutting Force	18Kgf-m;30Kgf-m
Horizontal placement	80KG	Ninety ° Time	50KG
