Product Description

The S20 series is designed for low torque, with displacement from 80 to 500ml/r.
S50 series for small displacement design, including 50, 63ml/r two displacement.
According to the need can be directly connected to the FK/FKS combination valve block, to meet the needs of a variety of systems.
Mainly used in tractors, combine harvesters, loaders, forklifts and other wheeled heavy-duty vehicles.

S20 Series Hydraulic Steering Control Unit

---Optimized control rotary valve design, superior performance
---Low hydraulic noise
---Casting inner channel design, small pressure loss
---Three basic types: open core, closed core and load sensing

Main performance parameters

Maximum inlet pressure………………16MPa
Maximum continuous back pressure………………2.1MPa
Steering torque
Low torque………………………………1.1~ 1.8Nm
Ultra-low torque……………………………1.1 ~ 1.4Nm
Maximum system temperature………………93°C
Recommended Oil Cleanliness………ISO 18/13

Product Features					Displacement/No.
Type	Connection	Oil port	80	100	125	160	200	250	280
Open core	Short stop	4-M20X1.5	S10-1101	-1102	-1103	-1104	-1105	-1106	-1100
No reaction	Long stop	4-M10	S10-1201	-1202	-1203	-1204	-1205	-1206	-1200
	Internal spline	2-M12	S10-1301	-1302	-1303	-1304	-1305	-1306	-1300
Closed core	Short stop	4-M20X1.5	S10-3101	-3102	-3103	-3104	-3105	-3106	-3100
No reaction	Long stop	4-M10	S10-3201	-3202	-3203	-3204	-3205	-3206	-3200
	Internal spline	2-M12	S10-3301	-3302	-3303	-3304	-3305	-3306	-3300
Static signal load sensing	Short stop	4-M20X1.5&M12X1.5	S10-5101	-5102	-5103	-5104	-5105	-5106	-5100
		Long stop	4-M10	S10-5201	-5202	-5203	-5204	-5205	-5206	-5200
		Internal spline	2-M12	S10-5301	-5302	-5303	-5304	-5305	-5306	-5300
Dynamic signal load sensing	Short stop	4-M20X1.5&M12X1.5	S10-7101	-7102	-7103	-7104	-7105	-7106	-7100
		Long stop	4-M10	S10-7201	-7202	-7203	-7204	-7205	-7206	-7200
		Internal spline	2-M12	S10-7301	-7302	-7303	-7304	-7305	-7306	-7300
Open core	Short stop	4-M20X1.5 'O'-ring(φ22.5)	S10-1121	-1122	-1123	-1124	-1125	-1126	-1120
No reaction	Long stop	4-M10	S10-1221	-1222	-1223	-1224	-1225	-1226	-1220
	Internal spline	2-M12	S10-1321	-1322	-1323	-1324	-1325	-1326	-1320
Closed core	Short stop	4-M20X1.5 'O'ring(φ21.8)	S10-3161	-3162	-3163	-3164	-3165	-3166	-3160
No reaction	Long stop	4-M10	S10-3261	-3262	-3263	-3264	-3265	-3266	-3260
	Internal spline	2-M12	S10-3361	-3362	-3363	-3364	-3365	-3366	-3360
Static signal load sensing	Short stop	4-M18X1.5&M12X1.5	S10-5171	-5172	-5173	-5174	-5175	-5176	-5170
		Long stop	4-M10	S10-5271	-5272	-5273	-5274	-5275	-5276	-5270
		Internal spline	2-M12	S10-5371	-5372	-5373	-5374	-5375	-5376	-5370
Open core	Short stop	4-G1/2	S10-1111	-1112	-1113	-1114	-1115	-1116	-1110
No reaction	Long stop	4-M10	S10-1211	-1212	-1213	-1214	-1215	-1216	-1210
	Internal spline	2-M12	S10-1311	-1312	-1313	-1314	-1315	-1316	-1310
Static signal load sensing	Short stop	4-3/4-16UNF'O'-ring&	S10-5151	-5152	-5153	-5154	-5155	-5156	-5150
	Short stop		S10-5151	-5152	-5153	-5154	-5155	-5156	-5150		7/16-20UNF 'O'-ring
		Long stop	4-3/8-16UNC	S10-5251	-5252	-5253	-5254	-5255	-5256	-5250
		Internal spline	2-3/8-24UNF	S10-5351	-5352	-5353	-5354	-5355	-5356	-5350
