Product Description

The planetary gearbox, wheel drive gearbox, winch drive gearbox and track drive gearbox produced by us have the same installation dimensions as Brevini riduttori, and the performance parameters are very close to Brevini riduttori, which can be used instead of Brevini riduttori's products.

EM1010	ED2010	ET3010	EQ4010	EC2010	EC3010	EC4010
EM1020	ED2020	ET3020	EQ4020	EC2020	EC3020	EC4020
EM1030	ED2030	ET3030	EQ4030	EC2030	EC3030	EC4030
EC4040	ED2040	ET3040	EQ4040	EC2040	EC3040	EC4040
EM1045	ED2045	ET3045	EQ4045	EC2045	EC3045	EC4045
EM1046	ED2046	ET3046	EQ4046	EC2046	EC3046	EC4046
EM1065	ED2065	ET3065	EQ4065	EC2065	EC3065	EC4065
EM1067	ED2067	ET3067	EQ4067	EC2067	EC3067	EC4067
EM1090	ED2090	ET3090	EQ4090	EC2090	EC3090	EC4090
EM1091	ED2091	ET3091	EQ4091	EC2091	EC3091	EC4091
EM1150	ED2150	ET3150	EQ4150	EC2150	EC3150	EC4150
EM1155	ED2155	ET3155	EQ4155	EC2155	EC3155	EC4155
EM1250	ED2250	ET3250	EQ4250	EC2250	EC3250	EC4250
EM1255	ED2255	ET3255	EQ4255	EC2255	EC3255	EC4255
EM1320	ED2320	ET3320	EQ4320	EC2320	EC3320	EC4320

CTD Series
CTD1020	CTD2051	CTD2100	CTD3150	CTD3200	CTD3300	CTD3500 CTD3700
CTU Series
CTU3150	CTU3200	CTU3300	CTU3500	CTU3700
PW Series
PWD2100	PWD3150	PWD3200	PWD3300	PWD3500	PWD3700
SL Series
SL3001	SL3002	SL3003	SL3004	SC3002	SC3003	SC3004
SL4001	SL4002	SL4003	SL4004	SC4002	SC4003	SC4004
SL6001	SL6002	SL6003	SL6004	SC6002	SC6003	SC6004
SL8501	SL8502	SL8503	SL8504	SC8502	SC8503	SC8504
SL12001	SL12002	SL12003	SL12004	SC12002	SC12003	SC12004
SL18001	SL18002	SL18003	SL18004	SC18002	SC18003	SC18004
SL25001	SL25002	SL25003	SL25004	SC25002	SC25003	SC25004
SL35001	SL35002	SL35003	SL35004	SC35002	SC35003	SC35004
SLS3002	SLS3003	SLS4002	SLS4003
RPR Series
RPR2046	RPR3046	RPR2065	PR3065	RPR2150	RPR3150	RPR2250
RPR3250	RPR2255	RPR3255	RPR2320	RPR3320	RPR2600	RPR3600
RPR2800	RPR3800

EP401T1

EP410T3

Track Drives Superior Performance
The EP400T Series track drives planetary gearbox is a specialized gear speed reducer for tracked vehicles and earth-moving machines. The reduction gearbox has a heavy-duty casing, a short overall length, and great radial and axial load capacity. Our track drive gearboxes are provided with an integral multi-disc parking brake and have been designed for the direct mounting of hydraulic plug-in motors. The careful selection of the materials and design allows our gear reducers to be used in even the most severe environments. EP400T Series gearboxes are the perfect transmission solution for crawler undercarriages, drilling, crushing, screening and piling machines.
Track Drives Key Features
1. Output torque range: 1000-450000N.m
2. Gear ratios: i=5.3-500
3. Support: thegearbox has rotating housing flanges to fit tracks
4. Applicable motors: axial piston hydraulic motors, hydraulic orbit motors or others
5. Hydraulic motor options: pressure relief valve, overcenter valve
6. Bearing: robust bearing system absorbing the forces exerted by the ring gear
7. Brake: hydraulic released parking brake
8. High torque and load capacities: to carry equipment over the roughest and steepest terrain.
9. Designed to allow mounting of plug-in motors.
10. Integral multi-disc parking brakes, while still keeping the drive compact.
11. Steel structure.
12. Easy maintenance: filling and draining openings are reasonably located for easy reach.
13. Front mechanical seal designed specifically for the earth-moving machines.
14. Technical data and installation dimension of NB400T Series gearbox are same as those of Rexroth GFT…T Series and Bonfiglioli 700C Series, so these three can be used interchangeably.

EP413T3

EP418T3

Type	Max. torque N.m	Range of ratios (i)	Max. Input speed (rpm)	Braking torque (N.m)
EP400T1	1300	6.09	1000	130
EP401T1	2000	6.2	1000	270
EP402T2	5000	12.4-37.1	3500	-
EP403T2	7000	15.4-40	3500	270
EP405T	10000	20-80	3500	270
EP405.4T	11000	26-57	3500	280
EP406AT	17000	23-220	3500	430
EP406T	18000	28-140	3500	430
EP406BT3	24000	63-136	3500	430
EP407AT	26000	38-136	3500	430-530
EP407T3	36000	63-136	3500	530
EP410T3	50000	62-177	3500	530
EP413T3	60000	86-172	3500	610
EP414T3	80000	76-186	3500	1200
EP415T3	110000	81-215	3000	1200
EP416T3	160000	87-255	3000	2000
EP417T3	220000	123-365	3000	2000
EP418T3	270000	166-364	3000	2000
EP419T3	330000	161-306	2500	3000
EP420T4	450000	296-421	2500	1700

Product Identification Scheme

1. EP/EPT: EVER-POWER GROUP / EVER-POWER TRANSMISSION
2. 413: Gearbox size, 400, 401, 402…417, 602, 603…615
3. T: Series, T…Track drive, W…Winch drive, L…Wheel drive
4. 3: Number of stages, 1…single stage, 2…double stage, 3…triple stage, 4…four stage
5. 139: Ratio
6. WO: With or without brake, WO…without brake, no symbol…with brake
7. A2FE63: Motor type
8. A: Motor shaft mark, A…A shaft motor, Z…Z shaft motor

1	2	3	4	5	6	7	8
EP/EPT	413	T	3	139	WO	A2FE63	A

Click here for more model types!

EVER-POWER GROUP is a Symbol of quality craftsmanship in China . Founded in 1988, specialize in the manufacturing of slewing drives , wheel drivck drives winch drives of gearboxes are used in a variety of applications including construction machine petroleum , coal , geological exploration , shipping , metallurgy , solar power , wind power , agriculture , andprotection .After years of developmental success , our products are intemational recognized for their quality . We export gearboxes to many places in the world , including Southeast Asia , the Middle East Germany , USA Canada Spain Australia , Turkey , and India . We are a consistently growing enterprise that seeks to satisfy our customatter their location
