RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox

RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox

Product Information Product Information Please tell us what you need: 1, Confirmed model: nmrv30, nmrv40, nmrv50, nmrv63, nmrv75, nmrv90, nmrv110, nmrv130 and so on 2, Confirm the reduction ratio: 5:1, 10:1, 15:1, 20:1, 25:1, 30:1, 40:1, 50:1, 60:1, 80:1, 100:1 3, Confirm ......Keywords:Rv030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox - Buy Worm Reducer Gearbox,Aluminium Alloy Worm Reducer Gearbox,Worm Gear Reducer Product on CMN Industry Inc

Send Inquiry

Product Description

Product Information






Please tell us what you need:



1, Confirmed model: nmrv30, nmrv40, nmrv50, nmrv63, nmrv75, nmrv90, nmrv110, nmrv130 and so on
2, Confirm the reduction ratio: 5:1, 10:1, 15:1, 20:1, 25:1, 30:1, 40:1, 50:1, 60:1, 80:1, 100:1
3, Confirm the input hole and output size: please refer to the detailed size table for the specific size
4, Confirm the size of motor flange: there are two kinds of large flange (B5) and small flange (B14), choose one.
5, Confirm the diameter of motor shaft hole: 11mm, 14mm, 19mm, 24mm, 28mm, 38mm
6, Confirm the motor specification: the standard configuration is a three-phase 380V motor with a speed of 1400rpm. If necessary: single phase 220 V motor, variable frequency motor, brake motor, 6-level motor, the price is determined separately.



NMRV040:





RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox

RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox





Type
Worm Gear Speed Reducer / Gearbox / Reductor
Model
NMRV25/30/40/50/63/75/90/110/130/150/185
Color
Customized Color
Packing
Carton, Honey Comb Carton, Wooden Case with Wooden Pallet
Usage
Industrial Machine, Food Stuff, Ceramics, Chemical, Packing, Dyeing, Wood Working, Glass, etc.
Flange
IEC standard flange or customized dimensions
Housing Material
Aluminum&Cast iron
Size
11 sizes(WMRV25~WMRV185)
Power
0.06~22 KW
Nominal torque
≤2548 N.m
Ratio
5~100





For more models, please click here!





RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox


















Warranty 3 years
Certification CE
Applicable Industries Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Energy & Mining
Gearing Arrangement Worm
Output Torque 740-1050
Input Speed 1400
Output Speed 14-186.7
Place of Origin China
China Zhejiang
Brand Name EPG
YNMRV Worm Reducer Gearbox OEM is welcome.
Color blue or gray or according to customer require
Product Display

RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox
RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox
RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox
RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox
RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox
RV030,040,050,063,075,090,110,130 Aluminium Alloy Worm Reducer Gearbox
